| Operation class | Class D |
|---|---|
| Number of Channels | 01 |
| Maximum power | @ 14.4 VDC - 1 Ohm: 3000 Watts RMS @ 14.4 VDC - 2 Ohms: 1920 Watts RMS |
| Input Sensitivity | 220mV |
| Signal to Noise Ratio | > 95dB |
| Frequency Response | 8Hz ~ 250Hz (-3dB) |
| Crossover high pass (HPF) | 8Hz ~ 30Hz (-12dB/8ª) Variable |
| Crossover low pass (LPF) | 60Hz ~ 250Hz (-12dB/8ª) Variable |
| bass boost | Freq.: 35Hz ~ 60Hz / Boost: 0 ~ +10dB |
| Efficiency | 80% |
| Input Impedance | 15K Ohms |
| Output Impedance | 1 Ohm |
| protection system | Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection |
| Min. Supply Voltage | 9 VDC |
| Maximum Power Supply Voltage | 17 VDC |
| Consumption at rest | 1.10A |
| Maximum music consumption | 130A |
| Maximum consumption in sinusoidal signal | 260A |
| Dimensions (WxHxD) | 9.41" x 2.87" x 8.58" (239 x 73 x 218mm) |
| Weight | 6.51lb (2.96Kg) |
| EAN | 7898556844789 |
